DOWNLOADS
SPECIFICATION-Standard
SPECIFICATION-ColorflipTM Tunable White
SPECIFICATION-ColorflipTM W+RGB
SPECIFICATION-ColorflipTM Warm Dim
INSTALLATION GUIDE-Stem
INSTALLATION GUIDE-Adjustable Cable
INSTALLATION GUIDE-Surface Mount
INSTALLATION GUIDE-Wall Mount
INSTALLATION GUIDE-Yoke Mount
INSTALLATION GUIDE-EMP Wiring Diagram
IES FILES-Standard
IES FILES-W+RGB
IES FILES-Warm Dim
REVIT FILES-Standard

This luminaire has been specified in a wide range of indoor project applications such as Corporate Spaces, Colleges, Auditoriums, and in the Hospitality sector. With a lumen package range of 1,300 lm to 5,600 lm, this luminaire can fit a variety of low ceiling heights and is also Damp Location rated.

This architectural indoor luminaire is also available with a field replaceable and decorative Glow Ring option for that high profile look. The prismatic lens also provides even light distribution and minimizes glare.

DIMENSIONS

FEATURES
Aesthetic and Contemporary Design
This luminaire features an ultra low-profile design with Glow Ring accessory for a strikingly decorative effect. Ideal for projects below 12 ft. mounting heights, this luminaire has been recognized by both the IES Progress Report Award and Product Innovation Award in 2016

Prismatic Lens for Minimal Glare
The prismatic lens features a 45 degree beam angle cut-off that minimizes glare. The chamber also allows for smoother light distribution and color mixing

Innovative Thermal Management
The luminaire features an innovative Thermal Beam Management design where the entire structure of the luminaire acts as a heat sink for better heat dissipation, reliability and life time

DETAILS
MODEL

ATRIA 4
WATTAGE

15 W
25 W
35 W
45 W
65 W
CCT

2700 K
3000 K
3500 K
4000 K
4000 K
LUMEN OUTPUT

1338 lm
2060 lm
2620 lm
4305 lm
5650 lm
DIMMING

TRIAC dims to 1%
ECOsystem dims to 1%
Superior 0-10V dims to 1%
Superior 0-10V dims to 10%
DMX dims to 0.1%
RATING

Dry Location
Damp Location
CRI

85
93
FINISH

Black
White
CERTIFICATIONS
