Architectural 4-inch Cylinder

Engineered for performance spaces, this architectural compact cylinder seamlessly integrates into ceilings, delivering powerful performance with vibrant, color-changing technology that elevates any stage environment. With its next-gen design, the Atria Mark II features an upgraded light engine that boasts a 30% increase in lighting output across the series, and a new SilentBlack™ finish that reduces reflectance to under 5%.

DIMENSIONS

Atria II 4 Dimensions

FEATURES
Brilliantly Versatile
With an impressive lumen output ranging from 2,175 to 8,260 lumens, coupled with advanced dimming options, full range of dynamic color changing options, and versatile mounting choices, the Atria II provides solution for a wide range of applications.

Aesthetic Glow Ring
The Atria II 4 offers an enchanting Glow Ring option that can be paired with other aperture sizes. This translucent ring offers a decorative aesthetic that creates a captivating display.

Double Reflector Design
With such a powerful luminaire, optimum glare control is crucial. This is achieved through a double reflector design in the housing trim, which positions the light source further back to ensure a better cutoff angle.

DLC Qualified
The Atria II now offers a higher and more extensive lumen range, qualifying it for DLC certification with an efficiency above 120 lm/W, delivering high energy savings and reliable illumination.

DETAILS
MODEL

ATRIA II 4
WATTAGE

15 W
25 W
35 W
45 W
65 W
CCT

2700 K
3000 K
3500 K
4000 K
4000 K
LUMEN OUTPUT

2,175 lm
3,215 lm
4,150 lm
6,235 lm
8,260 lm
DIMMING

TRIAC dims to 1%
ECOsystem dims to 1%
Superior 0-10V dims to 1%
Standard 0-10V dims to 10%
DMX dims to 0.1%
RATING

Dry Location
Damp Location
CRI

85
93
FINISH

Black
White
CERTIFICATIONS
